ATI 2.0 TRAIL SERIES 3″ FRONT/2″ REAR LIFT KIT – LONG TRAVEL – NISSAN NAVARA D23 NP300

Description

ATI 2.0 TRAIL SERIES 3″ FRONT/2″ REAR LIFT KIT



COMPATIBILITY:

• NISSAN NAVARA D23/NP300 2015 – CURRENT (COIL REAR)



Features:

• Long travel design
• OE style rubber bushings
• Fully servicable and rebuildable
• 3 Year unlimited KM warranty



Specifications:

• Body material: Seamless steel
• Body coating: EDP Coating
• Component Material: 6061-T6 Aluminium
• Component Coating: Anodize
• Seal brand: NOK
• Oil brand: Mobil
• Shaft diameter: 20mm
• Bore diameter: 52mm
• Front strut extended length: 460mm
• Front strut compressed length: 350mm
• Front strut travel: 110mm
• Rear shock extended length: 650mm
• Rear shock compressed length: 440mm
• Rear shock travel: 210mm



Kit Includes:

• ATI 2.0 Trail Series front struts (Pre set to approx 3″ lift)
• Height adjustment spanners
• ATI 2.0 Trail Series rear shocks
• Shock shaft protection boots
• ATI rear 2″ lift coil springs
• ATI adjustable upper control arms
• ATI front adjustable swaybar links
• ATI rear ajustable swaybar links
• ATI rear extended braided brake lines
• ATI headlight adjustment bracket
